Xiaomi Says “Revolutionary” Long-Range Wireless Charging is Here—Critics Say Otherwise

February 02, 2021 by Jake Hertz

Xiaomi claims its new smartphone-compatible technology offers wireless charging at a distance—with no stands or charging pads necessary.

While wireless charging (WC) sounds like a useful technology in theory, its full potential has been limited by design-level barriers.



The inductive charging process

The inductive charging process. Image used courtesy of Proxi and Computer World


Namely, the limited range of WCs has barred the full potential of Qi technology: sure, the technology is technically “wireless,” but if the phone has to be directly on the stand to work, does it really afford users that much freedom? At least a user can use their phone with some range (the length of the charging cable) while using wired charging.

While there are many companies working on WC at a distance, Xiaomi, one of the world's top smartphone makers, may actually have resources and commercialization rapport to make truly wireless charging a reality.



Xiaomi Announces Mi Air Charge Technology

Xiaomi's recent claim of a long-range wireless solution is not the company's first brush with wireless technology in general—an example being its Mi 10 Ultra smartphone, which is capable of 120 W wired charging and 50 W wireless. Compare that with the standard 5 W USB charging that most phones (iPhone included) offer, and it's clear why many tech media outlets call this feature a feat.

The company has now continued adding to its résumé of charging technologies with its new Mi Air Charge technology.



Mi Air Charge

Mi Air Charge includes a beacon antenna, which sends position information without high power consumption. Image used courtesy of Xiaomi


Xiaomi calls its Mi Air Charge a "revolution" in wireless charging, offering WC of multiple devices at once at a radius of several meters. The technology is said to provide up to 5 W of power for each device from a central beacon and charge through solid material without loss of efficiency.

While a standard USB wired charger will produce 5 W (5 V at 1 A), Xiaomi claims to be matching these numbers at a true distance. However, many engineers are understandably skeptical, arguing that the technology is unachievable or a flat-out hoax.

While it's impossible to fully size up the engineering feasibility of this technology without many released specs, we can review the details of Mi Charging technology that have been disclosed and assess how Xiaomi proposes it will work.



Charging at a Distance: How the Transmitter Works

According to Xiaomi, Mi Air charging technology, like Qi technology, consists of a transmitting device (dubbed by Xiaomi the “charge pile”), and a receiving device (the smartphone). The key to the technology is spatial positioning and efficient energy transfer.

The charge pile consists of a five-phase interference antenna array and a 144 antenna phase control array. The five-phase array detects signals from the smartphone homing beacon to accurately localize the smartphone. Then, the phase control array transmits millimeter waves to the phone through beamforming.



Graphic showing the concept of phased array antenna beamforming

Graphic showing the concept of phased array antenna beamforming. Image used courtesy of Radar Tutorial


We can assume that the charge pile’s phased array antenna arrays work on the principle of interference, where the superposition of several radiation sources can help the array localize a transmitter or direct its own transmissions.

By observing the interference patterns from the smartphone's homing beacon, the antenna array can determine the smartphone's location. In the same way, the charge pile can then transmit the millimeter waves to the smartphone via its antenna array.

The signal can be directed to its intended target at a distance when each antenna transmits different phase-shifted signals to constructively interfere in the direction of the receiver. This widely-used technique allows for purely electronic detection and steering of signals.



On the Receiver Side

On the receiver side (i.e the smartphone) the technology consists of a beacon antenna array and a receiving antenna array.

Using the methods described above, the beacon antenna transmits signals to the charge pile so the pile can determine the position of the smartphone. While this requires continuous transmission, Xiaomi claims this transmission requires very low power, so battery life should not be affected.

The receiving antenna array consists of 14 antennas that convert the millimeter waves into useful DC energy through its rectifying circuit. Because AC/DC conversion can be a large source of inefficiency, Xiaomi likely devoted plenty of attention to detail to the power efficiency of this rectifying circuit.



A MOSFET rectifier circuit with power factor correction

A MOSFET rectifier circuit with power factor correction. Image used courtesy of Texas Instruments


Academic research has proposed many ways in which AC/DC conversion can be made more efficient. One of the main sources of inefficiency in the standard bridge rectifier is the forward drop of the diode bridge.

A solution that's been widely accepted has been a digitally-controlled MOSFET bridge that behaves like a rectifier, but without the forward voltage drop that the diodes introduce. Other techniques include power factor correction, which attempts to force the voltage and current waveforms in phase.

If the company's claims are true (that this is the first long-range wireless charging technology that’s been integrated into a major smartphone brand), Air Charge presents some exciting possibilities in the electrical engineering world. However, at the time being, it's impossible to fully assess whether Xiaomi Air Charge is purely market hype or an engineering feat until the company releases concrete technical documentation.






What design challenges remain in the way of widespread adoption of true wireless charging? Share your thoughts in the comments below.

2 Comments
  • ANTALIFE February 05, 2021
  • D
    Dtodorov February 11, 2021

    I really like how they only show it working on a smooth video animations and they would talk about revolutionary technologies and future of ‘wireless’ and all sorts of good things it brings and yada yada yada. When in fact beam forming with antenna arrays is know for decades and all attempts at high power wireless energy transfer have been commercially unsuccessful. The mm wave frequency power rectification is insanely inefficient due to reverse recovery of diodes, and synchronous switching SiC at few GHz predicts huge switching losses (not to mention the EMI…).
    And then there are the problems of tracking the device itself, battling propagation losses in air and in other obstructions. Not to mention high power radiation heating effects over tissues.
