Cypress EZUSB Communication Core for FPGAs

It's a general purpose Cypress EZUSB communication core which was developed for ZTEX FPGA Boards and supports the following features:

• EZ-USB slave FIFO input
• EZ-USB slave FIFO output
• buffering and filtering of the interface clock from the EZ-USB
• Scheduler if both directions are active
• Automatic committing 'PKTEND' after timeout

Interface

The usage of this core is best described by a commented port definition:

module ezusb_io #( parameter CLKBUF_TYPE = "", // selects the clock preparation method (buffering, filtering, ...) // "SPARTAN6" for Xilinx Spartan 6,  // "SERIES7" for Xilinx Series 7,  // all other values: no clock preparation parameter OUTEP = 2, // EP for FPGA -> EZ-USB transfers parameter INEP = 6 // EP for EZ-USB -> FPGA transfers  ) ( output ifclk, // buffered output of the interface clock // this is the clock for the user logic input reset, // asynchronous reset input output reset_out, // synchronous reset output // FPGA pins that are connected directly to EZ-USB. input ifclk_in, // interface clock IFCLK inout [15:0] fd, // 16 bit data bus output reg SLWR, PKTEND, // SLWR (slave write) and PKTEND (packet end) flags output SLRD, SLOE, // SLRD (slave read) and SLOE (slave output enable) flags output [1:0] FIFOADDR, // FIFOADDR pins select the endpoint input EMPTY_FLAG, FULL_FLAG, // EMPTY and FULL flag of the slave FIFO interface // Signals for FPGA -> EZ-USB transfer. The are controlled by user logic. input [15:0] DI, // data written to EZ-USB input DI_valid, // 1 indicates valid data; DI and DI_valid must be hold if DI_ready is 0 output DI_ready, // 1 if new data are accepted input DI_enable, // setting to 0 disables FPGA -> EZ-USB transfers input [15:0] pktend_timeout, // timeout in multiples of 65536 clocks before a short packet committed // setting to 0 disables this feature // Signals for EZ-USB -> FPGA transfer. They are controlled by user logic. output reg [15:0] DO, // data read from EZ-USB output reg DO_valid, // 1 indicates valid data input DO_ready, // setting to 1 enables writing new data to DO in next clock // DO and DO_valid are hold if DO_ready is 0 // set to 0 to disable data reads  // debug output output [3:0] status );

Verilog instantiation example

This is an example instantiation in Verilog:

ezusb_io #( .OUTEP(2), // EP2 for FPGA -> EZ-USB transfers .INEP(6), // EP6 for EZ-USB -> FPGA transfers  .CLKBUF_TYPE("SERIES7") // selects the clock preparation method (buffering, filtering, ...) // "SPARTAN6" for Xilinx Spartan 6,  // "SERIES7" for Xilinx Series 7,  // all other values: no clock preparation ) ezusb_io_inst ( .ifclk(ifclk), .reset(reset), .reset_out(reset_usb), // pins .ifclk_in(ifclk_in), .fd(fd), .SLWR(SLWR), .SLRD(SLRD), .SLOE(SLOE), .PKTEND(PKTEND), .FIFOADDR({FIFOADDR1, FIFOADDR0}), .EMPTY_FLAG(FLAGA), .FULL_FLAG(FLAGB), // signals for FPGA -> EZ-USB transfer .DI(rd_buf[15:0]), .DI_valid(USB_DI_valid), .DI_ready(USB_DI_ready), .DI_enable(1'b1), .pktend_timeout(16'd73), // timeout in multiples of 65536 clocks (approx. 0.1s @ 48 MHz) before a short packet committed // signals for EZ-USB -> FPGA transfer .DO(USB_DO), .DO_valid(USB_DO_valid), .DO_ready((mode_buf==2'd0) && !reset_ifclk && !FULL), // debug output .status(if_status) );

VHDL instantiation example

A component declaration of the module can be found in file ezusb_io_component.vhdl This is the VHDL variant of the instantiation from above.

-- ...
signal reset2      : std_logic;
signal DO_ready    : std_logic;

begin

   ezusb_io_inst : ezusb_io
    generic map (
	OUTEP => 2,		        -- EP for FPGA -> EZ-USB transfers
	INEP  => 6 		        -- EP for EZ-USB -> FPGA transfers
    )
    port map (
	ifclk     => ifclk,
        reset     => reset,   		-- asynchronous reset input
        reset_out => reset_usb,		-- synchronous reset output
        -- pins
        ifclk_in   => ifclk_in,
        fd	   => fd,
	SLWR	   => SLWR,
	SLRD       => SLRD,
	SLOE       => SLOE,
	PKTEND     => PKTEND,
	FIFOADDR(0)=> FIFOADDR0,
	FIFOADDR(1)=> FIFOADDR1,
	EMPTY_FLAG => FLAGA,
	FULL_FLAG  => FLAGB,
	-- signals for FPGA -> EZ-USB transfer
	DI	       => rd_buf(15 downto 0),	-- data written to EZ-USB
	DI_valid       => USB_DI_valid,		-- 1 indicates data valid; DI and DI_valid must be hold if DI_ready is 0
	DI_ready       => USB_DI_ready,		-- 1 if new data are accepted
	DI_enable      => '1',			-- setting to 0 disables FPGA -> EZ-USB transfers
        pktend_timeout => conv_std_logic_vector(90,16),		-- timeout in multiples of 65536 clocks (approx. 0.1s @ 48 MHz) before a short packet committed
    						-- setting to 0 disables this feature
	-- signals for EZ-USB -> FPGA transfer
	DO       => USB_DO,			-- data read from EZ-USB
	DO_valid => USB_DO_valid,		-- 1 indicated valid data
	DO_ready => DO_ready,			-- setting to 1 enables writing new data to DO in next clock; DO and DO_valid are hold if DO_ready is 0
        -- debug output
	status	 => if_status
    );

    reset2
