CF FFT - Fast Fourier Transform Converter

CF FFT - Fast Fourier Transform Converter


Category: Arithmetic Core

Created: January 05, 2003

Updated: January 27, 2020

Other project properties

Development Status: Stable

WishBone compliant: No

WishBone version: n/a

License: n/a


Cores are generated from Confluence; a modern logic design language. Confluence is a simple, yet highly expressive language that compiles into Verilog, VHDL, and C. See Confluent for more info. The Fast Fourier Transform converts time or spacial information into the frequency domain and is one of the most popular DSP algorithms.


The FFT architecture is pipelined on a rank basis; each rank has
its own butterfly and ranks are isolated from each other using
memory interleavers. This FFT can perform calculations on
continuous streaming data (one data set right after another).
More over, inputs and outputs are passed in pairs, doubling the
bandwidth. For instance, a 4096 point FFT can perform a transform
every 2048 cycles.

Each file is stand-alone and represents a specific configuration.
The 2 parameters are:
- Number of Points
- Component (Real/Imag) Precision

All designs are pipelined with a synchronous enable and reset.

The configuration parameters are coded in the file names: cf_fft_4096_18.v
- 4K point FFT.
- 18 bit precision, real and imaginary. Total is 36 bits.

Current configurations:
- cf_fft_256_8
- cf_fft_512_8
- cf_fft_1024_8
- cf_fft_2048_8
- cf_fft_4096_8
- cf_fft_256_16
- cf_fft_512_16
- cf_fft_1024_16
- cf_fft_2048_16
- cf_fft_4096_16
- cf_fft_256_18
- cf_fft_512_18
- cf_fft_1024_18
- cf_fft_2048_18
- cf_fft_4096_18
