SD Card Controller for Secure Digital Card

SD Card Controller for Secure Digital Card


Category: Communication Controller

Created: March 27, 2009

Updated: January 27, 2020

Language: Verilog

Other project properties

Development Status: Stable

Additional info: Design done, FPGA proven, Specification done

WishBone compliant: Yes

WishBone version: n/a

License: LGPL


The core is a combined SD/SDHC controller, for Secure Digital-card. Two designs is available, one full-feature core utilizing DMA and one smaller for PIO.
The idea with the full-feature design is that it should provide as much performance as possible. Therefore it's build to stall the CPU as little as possible and offload it some computations, this is archived by:

  • Error and flow control performed mainly in hardware i.e user specify when sending a command what kind of error check he wants to be performed. Result is then set in the response registers also can be set to generate interrupt.
  • Command generation for writing/reading block of data is performed in hardware
  • Buffer descriptors is used to to queue read/write data transmissions (Less delay between data transmissions)
  • DMA for minimal CPU interruption as possible.

Versatile FIFO,



Full-feature core

  • 32-bit Wishbone Interface
  • DMA
  • Buffer Descriptor
  • Compliant with SD Host Controller Spec version 2.0
  • Support SD 4-bit mode
  • Interrupt-on completion of Data and Command transmission
  • Write/Read FIFO with variable size
  • Internal implementation of CRC16 for data lines and CRC7 for command line

Small-FIFO core

  • 8-bit Wishbone Interface
  • PIO
  • Compliant with SD Host Controller Spec version 2.0
  • Support SD 4-bit mode
  • Simple SW interface, 4 FIFO + 4 Registers


Data block length fixed to 512 Byte
No SD 1-bit mode
No SPI mode
No Hot Insertion (i.e. inserting a card when the bus is operating)
No multiple block operations/pre erase
