DE1 Olimex LPC-L2294 System

DE1 Olimex LPC-L2294 System


Category: Prototype Board

Created: November 18, 2009

Updated: January 27, 2020

Language: Verilog

Other project properties

Development Status: Alpha

WishBone compliant: Yes

WishBone version: n/a

License: LGPL


This project uses two off the shelf boards and interfaces them. The processor board used is a Olimex LPC-L2294 and the FPGA board is a Terasic DE1. A Olimex ARM-USB-OCD was used to load and debug the code. The boards were cabled together with floppy and hard drive cables. The entire setup cost less than $350.

The bridge from the wb_async_mem_bridge project is used to interface the External Memory Controller to the Wishbone bus on the FPGA. Currently the SRAM, GPIOs & HEX LED display is connected and there are plans to add the other interfaces on the DE1 as time permits.

Ecos has been ported and there are some simple examples of multithreading and interrupts. The shell interface was borrowed from redboot has been striped down and adapted to run in it's own thread.
