Logic Probe - Simple Logic Analyzer

Logic Probe - Simple Logic Analyzer

Details

Category: Testing / Verification

Created: December 20, 2013

Updated: January 27, 2020

Language: Verilog

Other project properties

Development Status: Stable

Additional info: FPGA proven

WishBone compliant: No

WishBone version: n/a

License: BSD

Description

LogicProbe is a very simple logic analyzer which can be run on
an FPGA in parallel with the "device under test". The analyzer
has a width of 128 data channels, and is 512 samples deep. It
has a trigger (i.e., it starts catching the channels when this
signal got active once), and a sample enable (i.e., it does only
sample the channels when this line is 1). It uses the block RAM
on the FPGA to store the samples in real-time. When the sample
buffer is full, it begins to transmit the samples through a UART
(also included in the code) over the serial line to a PC where
the sample values are stored in a file. A simple listing program
allows to view the samples as hexadecimal values.
