Peak to Peak Voltage Calculator (VP-P)

This calculator shows the peak-to-peak voltage (VP-P) value from the peak voltage, RMS voltage, or average voltage.

Inputs

Volts (V)



Output

Volts (V)

Voltage Peak-to-Peak Illustration

Using the Peak-to-Peak Voltage Calculator

The peak-to-peak voltage calculator finds the peak-to-peak voltage, $$V_{P-P}$$, from the peak voltage, $$V_{P}$$, rms voltage, $$V_{rms}$$ or average voltage, $$V_{avg}$$.

Equations

$$V_{P-P} = 2*V_{P}$$

$$V_{P-P} = 2\sqrt{2}*V_{rms} = 2.828*V_{rms}$$

$$V_{P-P} = \pi*V_{avg} = 3.141*V_{avg}$$

$$V_{P}$$: The maximum instantaneous value of a function as measured from the zero-volt level. For the waveform shown above, the peak amplitude and peak value are the same, since the average value of the function is zero volts.

$$V_{P-P}$$: The full voltage between positive and negative peaks of the waveform; that is, the sum of the magnitude of the positive and negative peaks.

$$V_{rms}$$: The root-mean-square or effective value of a waveform.

$$V_{avg}$$: The level of a waveform defined by the condition that the area enclosed by the curve above this level is exactly equal to the area enclosed by the curve below this level.
