AES128

AES128 Click to expand image

Details

Category: Arithmetic Core

Created: September 09, 2014

Updated: November 19, 2019

Language: Verilog

Other project properties

Development Status: Stable

Additional info: Design done, FPGA proven, Specification done

WishBone compliant: No

WishBone version: n/a

License: LGPL

Description

This is crypto core with AMBA support APB based on datasheet fom AES_SPEC If you liked our work is want to help contribute to the future progress of others who have seen help us by donating. PayPal - The safer, easier way to pay online!

GITHUB : https://github.com/GLADICOS

Bitcoin Donate : 16tCHCq1nMZVDQeYTVwFXjzz53hnHSA2Q3

GLADIC is a group of people working with integrated circuits in Latin America that have done some work with integrated circuits or participated in training in the part of the digital flow. We hope that our IPs are also vital in any way the proposal for those who want to use it and it goes to silicon. We encourage anyone to make a donation to the OpenCores to offer this opportunity to people to disclose their work and promote the development of microelectronics area.

About IP

This IP was developed in order to:

  • Concepts acquired in training in the digital stream
  • Integration with free software
  • Different forms of functional verification
  • Projects aimed at ASIC
  • IP facing low density - average
  • Promoting microelectronics interested people on Latin America
  • Teamwork

This block consists of an encryption and decryption core that have the ECB mode, CBC, CTR. These modes have different types of jobs that are described in the above referenced manual. Each of these modes possesses other sub modes that are encryption / decryption / key generation / decryption with derivative of the original key. Also possesses configuration modes for switching / errors / DMA which is done through the configuration register. During processing in any way you can tell been reading another register that indicates the current state that the IP.

Additional information

  • FPGA MODEL USED
    • xc3s500e-4ft256 OBS: This is only by software on ISE 14.7
  • AMOUNT CELLS USED
  • Logic Utilization Used Available Utilization
    Number of Slices 2383 4656 51%
    Number of Slice Flip Flops 2134 9312 22%
    Number of 4 input LUTs 3901 9312 41%
    Number of bonded IOBs 79 190 41%
    Number of GCLKs 1 24 4%
  • MAXIMUM FREQUENCY
    • Minimum period: 14.405ns (Maximum Frequency: 69.421MHz)

IP verification

As the OpenCores encourages the use of free tools to check RTL so I decided to use the vpi / pli interface with C / C ++ in icarus verilog simulator to perform functional verification AES 128. The preparation of the verification environment was to plan test cases that validate each of the features developed by design. These cases mounted on the environment are individual tasks that enabled individually configure the DUT so that each cycle their outputs meet the rules set out in understanding the verifier.

Finally a monitor to capture information and evaluate the result as the outputs are valid according the values already known. This environment does not have code coverage then there is no way to access how much code has been covered so far. We have the follow test cases:

  • AES_WR_ONLY
    • Checks for change in registers without the the bit that enabled the core to carry out a particular task is set.
    • Only 1 type of test without variation of the configuration register.
  • AES_WR_ERROR_DINR_ONLY
    • Verifies that change in the status register and other signs depending on the value in the configuration register.
    • There are 233 valid test possibility.
  • AES_WR_ERROR_DOUTR_ONLY
    • Verifies that change in the status register and other signs depending on the value in the configuration register.
    • There are 233 valid test possibility.
  • ECB_ENCRYPTION REGISTER / DMA / CCFIE
    • Set the DUT for encryption and wait until the status register / DMA / CCFIE is set. Once the operation is finished reading the result and sets the block to reset it to wait for the next operation.
    • There are 12 possible valid tests.
  • ECB_DECRYPTION REGISTER / DMA / CCFIE
    • Set the DUT for decryption and waits until the status register / DMA / CCFIE is set. Once the operation is finished reading the result and sets the block to reset it to wait for the next operation.
    • There are 12 possible valid tests.
  • ECB_KEY_GEN REGISTER / DMA / CCFIE
    • Set the DUT for key generation and expects the status register / CCFIE is set. DMA has no effect as it is feature is only valid when it involves the DINR / DOUTR registers.
    • There are 3 possible of valid tests.
    • For configuration involving DATATYPE field is valid only DOUTR / DINR.
  • ECB_DERIVATION_DECRYPTION REGISTER / DMA / CCFIE
    • Set the DUT for decryption and derivation of the original key and wait until the status register / DMA / CCFIE is set. Once the operation is finished reading the result and sets the block to reset it to wait for the next operation.
    • There are 12 possible valid tests.
  • CBC_ENCRYPTION REGISTER / DMA / CCFIE
    • Set the DUT for encryption and wait until the status register / DMA / CCFIE is set. Once the operation is finished reading the result and sets the block to reset it to wait for the next operation.
    • Register IV is used in this mode.
    • There are 12 possible valid tests.
  • CBC_DECRYPTION REGISTER / DMA / CCFIE
    • Set the DUT for decryption and waits until the status register / DMA / CCFIE is set. Once the operation is finished reading the result and sets the block to reset it to wait for the next operation.
    • Register IV is used in this mode.
    • There are 12 possible valid tests.
  • CBC_KEY_GEN REGISTER / DMA / CCFIE
    • Set the DUT for key generation and expects the status register / CCFIE is setados. DMA has no effect as it is feature is only valid when it involves the DINR / DOUTR registers.
    • Register IV is used in this mode.
    • There are 3 possibilities of valid tests.
    • For configuration involving DATATYPE field is valid only DOUTR / DINR.
  • CBC_DERIVATION_DECRYPTION REGISTER / DMA / CCFIE
    • Set the DUT for decryption and derivation of the original key and wait until the status register / DMA / CCFIE is set. Once the operation is finished reading the result and sets the block to reset it to wait for the next operation.
    • Register IV is used in this mode.
    • There are 12 possible valid tests.
  • CTR_ENCRYPTION REGISTER / DMA / CCFIE
    • Set the DUT for encryption and wait until the status register / DMA / CCFIE is set. Once the operation is finished reading the result and sets the block to reset it to wait for the next operation.
    • Register IV is used in this mode.
    • There are 12 possible valid tests.
  • CTR_DECRYPTION REGISTER / DMA / CCFIE
    • Set the DUT for decryption and waits until the status register / DMA / CCFIE is set. Once the operation is finished reading the result and sets the block to reset it to wait for the next operation.
    • Register IV is used in this mode.
    • There are 12 possible valid tests.
  • CTR_KEY_GEN REGISTER / DMA / CCFIE
    • Set the DUT for key generation and expects the status register / CCFIE is setados. DMA has no effect as it is feature is only valid when it involves the DINR / DOUTR registers.
    • Register IV is used in this mode.
    • There are 3 possibilities of valid tests.
    • For configuration involving DATATYPE field is valid only DOUTR / DINR.
  • CTR_DERIVATION_DECRYPTION REGISTER / DMA / CCFIE
    • Set the DUT for decryption and derivation of the original key and wait until the status register / DMA / CCFIE is set. Once the operation is finished reading the result and sets the block to reset it to wait for the next operation.
    • Register IV is used in this mode.
    • This mode is forbidden for CTR and this configuration is setted the configuration register must be changes for decryption.
    • There are 12 possible valid tests.
  • SUFLE_TEST
    • This is to be used to check all cases tests with random data only.
    • There are 233 valid test possibility
  • RESET
    • Implements random resets at certain times during the execution of any BFM.
    • Reset entire environment.

TOTAL TESTS :
