Synthesizeable Radix 4 Complex FFT Processor

Synthesizeable Radix 4 Complex FFT Processor


Category: Arithmetic Core

Created: October 29, 2002

Updated: January 27, 2020

Other project properties

Development Status: Stable

WishBone compliant: No

WishBone version: n/a

License: n/a


This is synthesizeable radix 4 complex fft processor. Input data width and points are configurable. Output data width = Input data width + 2. Some necessary limited and shift have been done at every butterfly.

A sample implementation of a 1024 point 12 bit FFT runs at about 97MHz in a Spartan2e100 -6 device and occupies 1,271 LUTs (about 52%) and 1,144 registers (about 47%) of the device.


- Data width configurable
- Point configurable
- Input data during data output
- Simulation result has compare with Matlab result


- Design is available in VHDL from OpenCores CVS via cvsweb or via cvsget
- ...
