HDLC Controller
Details
Category: Communication Controller
Created: September 25, 2001
Updated: January 27, 2020
Other project properties
Development Status: Stable
WishBone compliant: Yes
WishBone version: n/a
License: n/a
Description
Features
- 8 bit parallel backend interface
- use external RX and TX clocks
- Start and end of frame pattern generation
- Start and end of frame pattern checking
- Idle pattern generation and detection (all ones)
- Idle pattern is assumed only after the end of a frame which is signaled by an abort signal
- Zero insertion
- Abort pattern generation and checking
- Address insertion and detection by software
- CRC generation and checking (Optional, external, since CRC-16 or CRC-32 can be used)
- FIFO buffers and synchronization (External)
- Byte aligned data (if data is not aligned to 8-bits extra random bits are inserted)
- Q.921, LAPB and LAPD compliant.
- For complete specifications refer to spec document
Status
The VHDL code is ready in the opencores CVS. The code needs verification contact me if you are intrested in helping me.
- also see Download section
Resource usage
Rx Channel Block: which includes HDLC Framing extraction, zero removal and conversion from serial to parallel.
Vendor | Device | Size | Frequency |
Board Tested |
Functional Test |
Notes |
Altera |
EP20K100BC356-3 |
108 LCs |
91.48MHz |
- | - | No optimization was performed, using Quartus II |
Tx Channel Block: which includes HDLC Frame generation, zero insertion and conversion from parallel to serial.
Vendor | Device | Size | Frequency |
Board Tested |
Functional Test |
Notes |
Altera |
EP20K100BC356-3 |
100 LCs |
112.42MHz |
- | - | No optimization was performed, using Quartus II |
HDLC controller Block: which includes both the Rx and Tx channels, FCS-16 generation and checking, 128 byte buffering for each direction and Wishbon SOC bus interface and controller registers.
Vendor | Device | Size | Frequency |
Board Tested |
Functional Test |
Notes |
Altera |
EP20K100BC356-3 |
630 LCs, 2 ESBs |
CLK_I=74.02, RxClk=101.86, TxClk=106.42 |
- | - | No optimization was performed, using Quartus II |
Links
- http://www.rad.com/networks/1994/hdlc/hdlc.htm
- http://www.erg.abdn.ac.uk/users/gorry/course/dl-pages/hdlc-framing.html
- http://members.tripod.com/~vkalra/hdlc.html
- http://goanna.cs.rmit.edu.au/~ivan/cs361/lec/lec5.pdf
- http://www.inicore.com/____pdf/inihdlc.pdf
- http://www.mentorg.com/inventra/netlist_program/actel/ds/hdlccoreA1_pd.pdf
