32-bit Configurable Wishbone MMC/SD Card Controller

32-bit Configurable Wishbone MMC/SD Card Controller


Category: Communication Controller

Created: September 01, 2013

Updated: January 27, 2020

Language: Verilog & VHDL

Other project properties

Development Status: Beta

Additional info: Design done, FPGA proven, Specification done

WishBone compliant: Yes

WishBone version: n/a

License: LGPL


The Wishbone SD Card Controller IP Core is MMC/SD communication controller designed to be
used in a System-on-Chip. The IP core provides a simple interface for any CPU with Wishbone
bus. The communication between the MMC/SD card controller and MMC/SD card is performed
according to the MMC/SD protocol.


A lot of effort has been put forth to make the core more generic and easily usable with OSs like Linux.
- data transfer commands are not fixed
- data transfer block size is configurable
- multiple block transfer support
- R2 responses (136 bit) support


The MMC/SD card controller provides following features:

- 1- or 4-bit MMC/SD mode (does not support SPI mode),
- 1-, 4- and 8-bit MMC bus size supported in VHDL version,
- 32-bit Wishbone interface,
- DMA engine for data transfers,
- Interrupt generation on completion of data and command transactions,
- Configurable data transfer block size,
- Support for any command code (including multiple data block tranfser),
- Support for R1, R1b, R2(136-bit), R3, R6 and R7 responses.


The documentation is located in the doc/ directory of the svn repository.
The VHDL version has some slight changes, and has it's own document called "sd_card_pack_OC120116"


A sample ORPSoC project that make use of this core is located at:


The project is based on de0_nano board with custom made expansion board
with SD Card connector.

There is also u-boot project port for this board located at:


This u-boot project contains driver for Wishbone SD Card Controller IP Core
and can be configured for de0_nano board (with custom made expansion board).

Also in the plan is the driver for Linux. The initial work can be found at:

https://github.com/mczerskilinux - de0_nano branch

the driver is named ocsdc and is located in drivers/mmc/host directory.


- top level testbench cleanup (sd_controller_top_tb.sv)
- rx/tx fifo treshold to do block transfers rather than many single word transfers
- maybe one fifo rather than two fifos (rx and tx) would suffice since the transfer
between card and controller is always half-duplex
- read only and card detect signals support
- timeout watchdog for data transfers
