Wishbone DDR3 SDRAM Controller Verilog

Wishbone DDR3 SDRAM Controller Verilog


Category: Memory Core

Created: July 27, 2016

Updated: January 27, 2020

Language: Verilog

Other project properties

Development Status: Planning

Additional info: Specification done

WishBone compliant: Yes

WishBone version: n/a

License: GPL


The purpose of this core is to provide a GPL wishbone core capable of commanding a DDR3 memory, such as the one used on Digilent's Arty board, at full speed. A particular design goal is that consecutive reads or writes should take only one additional clock cycle per read or write. My eventual goal is to build this so that it will support my OpenArty project.

Since the DDR3 memory specification is dated August, 2009, memory chips have been built to this specification. However, since the DDR3 SDRAM's are rather complex, and there is a lot of work required to manage them, controllers for DDR3 SDRAM's are primarily in the realm of proprietary.

Currently, as of this posting (20160728), there are no DDR3 SDRAM controllers on OpenCores. Sure, there's a project named DDR3 SDRAM controller, yet it has no data files present with it. This leaves an FPGA engineer with the choice of building a controller for a very complex interface from scratch, or using a proprietary core from Xilinx's Memory Interface Generator (MIG--assuming Xilinx is being used), for which there is no insight into how it works, and then retooling their bus from wishbone to AXI.

This core is designed to meet that need: it is both open (GPL), as well as wishbone compliant. Further, this core offers 32--bit granularity to an interface that would otherwise offer only 128-bit granularity. This core also offers complete pipelined performance. Because of the pipeline performance, this core is appropriate for filling cache lines. Because the core also offers non-pipelined performance, it is also appropriate for random access from a CPU-whether by a write-through cache or a CPU working without a cache.

Current Status

As anyone who has worked with DDR3 memory controllers will know, this is a difficult and complex project. There are lots of parts and pieces to it. Currently, a large portion (not all) of the Verilog code has been built, together with what should be a very thorough Verilator test bench. The Verilator code successfully brings the memory out of a reset condition, and starts its first write command. The next step will be completing this write command, and finishing the read logic.

Watch this space, if you are interested.


20160730 Update:

The good news is that reset works, as do single 32-bit value writes (in the included Verilator simulation ...)

The other good news is that I should be able to calculate timing. So, if you wish to write N adjacent values in a pipelined fashion, the amount of time it will take will be between 55+5N (ns) and 95+5N (ns), depending upon whether or not the corresponding bank is open at the write or wrong value.


20160801 Update:


20160802 Update:

I also learned more about Xilinx's ODDR and IDDR primitives, and so I fixed some bugs there.

This leaves me with two problems: 1) Fixing the timing issue broke the simulation, and 2) while testing at 160MHz without the timing fix, the answers and results from the memory were all over the map. I may be able to read and write 1/16 times, and I can't explain why that one time works.

Tomorrow, I shall try to see if I can't user an iserdese2 as a logic analyzer to see what's really going on---once I get the simulation logic fixed (again).


20160803 Update:


20160805 Update:

At any rate, I'm scratching my head on the drawing board right now. Since the commands must be issued in parallel, it makes sense to reserve timeslots for each command: The first could be reserved for Write, then Read, then Activate (open), then Precharge. This would allow precharge to be followed by an activate 11 clocks later, followed by a read, followed by a full vector-width read, as in:

Clk TS1 TS2 TS3 TS4 Internal Bus
2 NOOP NOOP NOOP NOOP Registered (Idle, or stalled if active)
3 NOOP NOOP NOOP Pre-Charge Stalled
4 (2) (3) (4) (5) Stalled
5 (6) (7) (8) (9) Stalled
6 (10) (11) Activate (2) Stalled
7 (3) (4) (5) (6) Stalled
8 (7) (8) (9) (10) Stalled Potential next bus command
9 (11) READ (2) (3) Next Cmd (Idle)
10 (4) (5/nxt read?) (6) (7)
11 (8) (9) (10) (11)
12 128-bit Data Transfer
13 (Determined by next command, otherwise idle)   ACK, and data returned


This is my plan going forward, but it may mean that I have to scrap a lot of what I've done.


20160816 Update:

I've spent my time going back over the specification and marking it up. As I last mentioned, I'll need to run this with a 1.25ns clock. That means that we can transfer 128 bits per clock on the data lines. It also means that, if this core is to run with a 5ns clock, that the core will issue four commands to the memory at any given 5ns clock. Some pictures might help explain that. First is a picture showing what a read will look like:


Here's another diagram showing what a write will look like. Notice the two sets of columns. The first is the command column, consisting of four 1.25ns commands per 5ns clock. A "P" is a pre-charge command, an "A" is an activate command, a "N" is a NOOP, a "Wx" is a write command, and a "Rx" is a read command, and so forth. Later, we'll use "R" to refer to a refresh command.


Our last image shows a refresh cycle:


I'm developing other, similar, images to understand how the timing will play out from one command to the next, but those aren't nearly as pretty to show at this time.


20160818 Update:

Hence a read is going to look like (now)


20160819 Update:

My task for next week will be trying to get this onto hardware. The good news is that I'll only need an x4 SERDES capability. I might use the x8 anyway, and use the extra bit for sample picking, but ... I'm at least moving forward.

20160823 Update:


20160902 Update:

After a quick chat with Digilent, I was informed that the low power Artix-7 on the Arty board can't handle the DDR1600 rates, and hence the DDR1333 performance.

In a moment of frustration, I thought to try the Xilinx Memory Interface Generator. Frustration lead to disappointment as I realized the Xilinx MIG would neither run at 200MHz nor 100MHz, nor any simple multiples of the above. Further, the interface claimed a 20+ clock delay, and it wasn't clear how to interface AXI to wishbone at all. This led me to ask Xilinx, why won't the MIG allow me to generate the 2:1 controller at 200MHz that I was hoping for? Again, I was told that the chip on the Artix-7 can't handle the data rate. In particular, I wanted it to handle a data rate of 800Mb/s, whereas the chip can only handle 667 Mb/s (4:1 mode) or 620 Mb/s (2:1) mode.

This places some tight restrictions on the memory clock. As per the DDR3 spec, the memory clock cannot be slower than 303MHz. When you couple this with the specification for my chip, the memory clock must be between 303 and 333 MHz, assuming a 4:1 memory command clock to system clock ratio, or equivalently my system clock must be between 76MHz and 83MHz. If I want to use the 2:1 memory command clock to system clock rate, my system clock must be between 152 and 155 MHz. Making matters worse is the fact that I wanted my system clock, network clock (25MHz), and UART (4MBaud) to all be nice multiples of each other. 200MHz would've made that work. This leaves me with the closest thing I can get being an 80MHz system clock, and anything faster will need to suffer a clock transfer delay.

So I now need to retool this project (once again) for an 80MHz clock, and a 4:1 memory clock to system clock ratio. Going back to the DDR3 specification, that means our access times will be (5-5-5) (clocks at 320MHz). This will slow down our access time by about 2ns, and our transfer time down from 10ns/128bits down to 12.5ns/128bits.

Perhaps I'm trying to hard: what's 2.5ns between friends anyway?

At any rate, here are some updated memory read, memory write, and refresh timing diagrams.



I expect it'll take a bit longer to get the Verilog code (and simulation) running with these new numbers, but that'll be my next step.


20160916 Update:

I then tried Xilinx's Memory Interface Generator core, and got it up and running using a simple bus translator. Much to my shock, their core requires about 24 clocks, at 81.25MHz, per transaction. (You can still see my testing work: it was done as part of the OpenArty project). Where did all this time go? You can see from our timing diagrams, that 9 clocks is more reasonable. The bus translator then adds a clock in the front, and two clocks at the end, leading to a 27 clock delay from strobe to ack. Need I say it again? This is pitiful!

So I got back to work today, and got the logic up and running, and passing all my simulator tests. While I'd like to say that it is now ready for the FPGA, it isn't. While the logic works in Verilator, and while it passes a fairly rigorous test suite, the source code has been so abused every time it has been "rewritten" that it really needs to be cleaned up first. There are variables in there that aren't used, variables that I don't know what they do, and more/worse. Once cleaned up though, it'll be time to head back to the FPGA and see if I can't get it running again.
